N50 magnets for sale D30 x 10mm +/- 0.1mm disc magnet industrial magnetics from China manufacturer

N50 magnets for sale D30 x 10mm +/- 0.1mm disc magnet industrial magnetics

Price:	0.01~100.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: RS-DM3010

Production Capacity: 100ton/month

Delivery Date: 25-30 days

Application: Industrial Magnet

Composite: Neodymium Magnet

Grade: N50

Tolerance: +/- 0.1mm

Plating/Coating: NiCuNi

Weight: 53.72g

Means of Transport: Ocean,Air;International Exp...

Packing: Standard seaway packing

Shape: Disc

Type: Permanent

Brand Name: Risheng

Dimensions: D30 x 10mm

Magnetization Direction: Axial

Max. Temp: 80°C

Pull Force: 25.506 kg

Disc magnets can be used in medical machine, DIY envelope, on fridge, toys etc., they are good to grip and strong in holding. Size diverses widely.

Description

Material: N50 Neodymium Magnet
Dimension: D30 x 10mm
Tolerance: +/- 0.1mm
Magnetization: Axially magnetized
Coating: NiCuNi
Weight: 53.72g
Pull Force: 25.506kg
Max. Working Temp.: 80°C
Surface Field: 4,022 GS

N50 4,022 GS D30 x 10mm NdFeB discs are used in many applications, particularly sensing and clamping applications.
The magnets are supplied in stock sizes varying from 1.5mm to 100mm in diameter and 0.5mm to 30mm in height. The stocks are supplied with +/-0.1mm tolerances and exist in axial and diametric magnetizations. Please note that the pull forces shown are theoretical maximums and may not be achieved in practice (it depends on the application as to the maximum force that is achieved).
We can produce the NdFeB circular magnets in different sizes, different grades (strengths and temperature ratings), different coatings/finishes and in axial and diametric magnetization as part of our custom magnet (made-to-order) service.
